| Brand | : Furuno |
| SKU Produk | : I03K034SK0157JP1154P13096 |
| Warna Tersedia | : Putih |
Rp. 1.950.000,- / Unit
antenna gps model GPA-017 dipergunakan untuk gps furuno model GP-32, GP25, dan GP-27.
| Input Frequency | 1575.42MHz±1.023MHz |
| Polarization | R. H. C. P. (Right Hand Circular Polarization) |
| Antenna Gain | <= 2.0dBi (at 90° elev. angle) <= -4.0dBi (at 10° elev. angle) |
| Output Impedance | 50 ? |
| Pre. Amp Gain | 27.5±5.5dB |
| Pre. Amp Noise Figure | <= 1.6dB |
| VSWR | <= 2.0 |
| Supply Voltage | 4 to 5.5VDC |
| Power Consumption | <= 25mA |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -35°C to +75°C |
| Operating Relative Humidity | <=95%RH |
| Connector Type | TNC-J |
| Note | Standard type |
